Datalogic MAGELLAN 8400 - IBM USB Cable Pinout; Scanner and Scale

IBM USB Cable Pinout
Product Reference Guide B-5
IBM USB Cable Pinout
Scanner and Scale
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-4IBM USB Cable Pinouts
PIN # FUNCTION DESCRIPTION
1 N/C No Connection
2 N/C No Connection
3 VBUS USB VBUS
4 USB D- USB D-
5 N/C No Connection
6 USB D+ USB D+
7 N/C No Connection
8 N/C No Connection
9 GND Signal Ground
10 N/C No Connection
