PROGRAMMING STRINGS
7
3
Bit Field (Type = 3)
Item List
List of the allowed values of the parameter.
Selection
Maximum number of values selectable at the same time (normally the number of items
available in the list - 1).
Default
Default entries (i.e. 0 = first entry of the list (not considered), 2
0
= second entry of the list, 2
1
=
third entry of the list).
Default value is given by the sum of the selected entries of the Item List.
Example
: OUTPUT 1 Activation Events parameter
Type: 3
Label: Activation Events
Item List
None, Complete Read, Partial Read, No Read, Acquisition Trigger, Phase
ON, Phase OFF, Run Mode, Host Control Mode, ISO-IEC Symbol Contrast,
ISO-IEC Print Growth, ISO-IEC/AIM DPM Axial Non Uniformity, ISO-IEC/AIM
DPM Unused ECC, ISO-IEC Modulation, ISO-IEC Min Edge Contrast, ISO-
IEC Decodability, ISO-IEC/AIM DPM Fixed Pattern Damage, ISO-IEC/AIM
DPM Grid Non Uniformity, ISO-IEC/AIM DPM Minimum Reflectance, ISO-IEC
Defects, ISO-IEC/AIM DPM Decode, AIM DPM Cell Contrast, AIM DPM Cell
Modulation, AS9132 Dot Size/Cell Fill, AS9132 Dot Center Offset, AS9132
Dot Ovality, AS9132 Quiet Zone, AS9132 Angle Of Distortion, AS9132
Symbol Contrast.
Selection: 19
Default: 6 (2
1
+ 2
2
Partial-Read + No-Read)
Caution: The first entry (None) can only be selected by setting the parameter value
to 0.
Example
:
Run Mode: entry 7 (-1) value = 2
6
= 64.
Partial Read + No Read: entry 2 (-1) + entry 3 (-1) value = 2
1
+ 2
2
= 6.
ISO-IEC Modulation: entry 13 (-1) value = 2
12
= 4096
