Datalogic Memor 10 User Manual

Introduction
User’s Manual 5
EEA Models (Coming 2H 2019)
• 944350014 Memor 10 Full Touch PDA, EEA, Wi-Fi + LTE,
Ultra-slim 2D Imager w Green Spot, Android v8.1 with GMS,
Black Color.
• 944350015 Memor 10 HC Full Touch PDA, EEA, Wi-Fi + LTE,
Ultra-slim 2D Imager w Green Spot, Android v8.1 with GMS,
White Color.
• 944350016 Memor 10 Full Touch PDA, Russia, Wi-Fi + LTE,
Ultra-slim 2D Imager w Green Spot, Android v8.1 with GMS,
Black Color.
For further details about the Memor 10 models refer to the web site:
http://www.datalogic.com.
For further information regarding Android refer to the website:
www.android.com.

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
