Datalogic Memor 10 User Manual

Battery
User’s Manual 15
Charge the Battery
The battery pack is not initially fully charged. After installing the
battery, charge it with the USB Type-C or with a dock (single slot
dock, 3-slot dock, vehicle dock).
During the charging process the charging LED positioned at the top
left side of the display glows red constantly. Once the charging
process has been completed, the charging LED glows green
constantly.
Charge with USB
Use the provided USB Type-C cable in conjunction with the power
supply adapter (p/n 94ACC0196) to charge the device from a power
outlet.
The charger is modular, with one adapter and four switchover plugs.
NOTE
Connection through the cable complies to USB Type-C
standard.

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
