Datalogic Memor 10 User Manual

Connections
User’s Manual 133
Near Field Communication (NFC)
NFC technology allows short-range, wireless data transfer between
the terminal and NFC tags or other NFC enabled devices placed in
close proximity to the back of the terminal.
Memor 10 support the following modes of operation:
• NFC tag reader/writer mode: the terminal reads and/or
writes digital information from or to an NFC tag.
• Peer-to-Peer (P2P) mode: the terminal uses Android Beam
and/or Bluetooth@ technology to transfer screen content
(e.g., a picture, web page url, or file) between NFC enabled
devices.
•NFC card emulation mode - The terminal emulates an NFC
card (smart card) that an external card reader can access.
Read NFC Tags
1. Make sure NFC is enabled (see NFC on page 68).
2. Hold the NFC tag close to the back of the terminal.
3. When an NFC tag is recognized, the terminal emits a sound and
the tag data displays on the terminal screen.
NOTE
Suspend mode and the screen lock temporarily turns the
NFC radio off.

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
