Datalogic Memor 10 User Manual

Connections
User’s Manual 129
WWAN Connection
The Memor 10 enhances your connectivity solutions giving you an
opening to an international wireless infrastructure that is the global
standard. It is optimized for the following two-way communications:
• Voice: GSM voice data (dial-up)
• Data: Available speed depends on the wireless network carrier
and their supported packet-data technology in addition to
network conditions.
The Memor 10 supports the following 3G bands:
• EU (ROW) : WCDMA 2100/850/900, CDMA2000 BC0
• US: WCDMA 2100/1900/1700/850/900, CDMA2000 BC0/1.
The Memor 10 supports the following LTE bands:
• EU (ROW) sku: FDD_LTE B1/3/5/7/8/20/28, TDD_LTE
B38/39/40/41
• US sku: FDD_LTE B2/4/5/7/12/13/17/25/26.
In order to use a WWAN Connection you have to install a SIM Card
(Install the MircoSIM Card on page 27).

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
