Datalogic Memor 10 User Manual

Settings
74 Memor™ 10
Recovery Mode
Recovery is an independent, runtime environment that’s included on
a separate bootable partition from the main Android OS. It contains
tools to help repair your installations as well as install official OS
updates by using a combination of key presses. Its main purpose is
to reset the device, wipe data or perform system updates when the
system crashes and the screen is unresponsive.
To enter boot menu:
1. Turn off the Memor 10 (see on page 18).
2. Press the power button and the volume up button simultaneously.
3. The device turns on and the Boot Menu appears. Select Recovery
Mode.
4. Use the volume up/down buttons to navigate the menu. You can
apply/force updates and perform a configuration reset. Press the
power key to select.

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
