Datalogic Memor 10 User Manual

Safety and Regulatory Information
User’s Manual 161
Radio Type Description Frequency
Maximum Output Power
Radio
Technology
Transmit
Frequency
Transmit Power
Receive
Frequency
GSM 900
B80 MHz
to 915 MHz
GSM/GPRS:32.2 dBm
EDGE:24.7 dBm
925 MHz
to 960 MHz
GSM1800
1710 MHz
to 1785 MHz
GSM/GPRS:29.7 dBm
EDGE:23.6 dBm
1805 MHz
to 1880 MHz
WCDMA band I
1920 MHz
to 1980 MHz
22.S dBm
2110 MHz
to 2170 MHz
WCDMA bandVIII
880 MHz
to 915 MHz
22.83 dBm
935 MHz
to 960 MHz
LTE FDD1
1920 MHz
to 1980 MHz
22.65 dBm
2110 MHz
to 2170 MHz
LTE FDD3
1710 MHz
to 1785 MHz
22.97 dBm
1805 MHz
to 1880 MHz
LTE FDD7
2500 MHz
to 2570 MHz
22.96 dBm
2620 MHz
to 2690 MHz
LTE FDD8
880 MHz
to 915 MHz
23.21 dBm
925 MHz
to 960 MHz
LTE FDD20
832 MHz
to 862 MHz
22.82 dBm
791 MHz
to 821 MHz
LTE FDD28
703 MHz
to 748 MHz
22.75 dBm
758 MHz
to 803 MHz
LTETDD38
2570 MHz
to 2620 MHz
22.69 dBm
2570 MHz
to 2620 MHz

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
