Datalogic Memor 10 User Manual

Getting Started
54 Memor™ 10
LED Indicators
The LEDs illuminate to indicate various functions or errors on the
reader. The following tables list these indications. The good read LED
indicator is programmable, and may or may not be enabled (Scanner
Settings on page 76 for more details).
LED Status Description
Charging LED
Red Constant The device is charging.
Green Costant Charging is complete.
Red Blink Charge fault.
Good Read
Indicator
Red
Light is solid red from the time the user
presses the scan key until the barcode is
decoded, until the scanner times out, or
until the user releases the scan key.
Green
Light changes to solid green when a
good decode is completed.

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
