Datalogic Memor 10 User Manual

Technical Features
140 Memor™ 10
Reading Performance
Camera
Resolution: 13 megapixel; Illumination: User
controllable LED flash; Lens: Auto focus
Scan Engine
2D Ultra slim area imager (supports 1D / 2D codes);
Datalogic’s ‘Green Spot’ for good-read feedback;
Depth of Field: 5 to 46 cm / 2 to 18 in depending on
bar code density and type;
Resolution: VGA (640 x 480 pixels);
Illumination: White LED; Aiming: Blue LED;
Field of View: 48°H x 34°V
Print Contrast (Minimum) 25%
Minimum Element Width
1D Linear: 0.1016mm / 4mils
PDF: 0.1676mm / 6.6mil
Data Matrix: 0.1905 mm / 7.5mil
Software
Applications
Datalogic’s SoftSpot technology for configurable
soft triggers; Supports Datalogic’s Queue Busting
app; Pre-licensed device and browser lockdown
powered by 42Gears; Enterprise class PTT offered by
Zello
Provisioning
Android Zero Touch enrollment and QR Code or NFC
Bump provisioning
Configuration and
Maintenance
Datalogic DXU for device configuration and firmware
upgrade from PC
Development Java and Xamarin SDK available
MDM
SOTI MobiControl, VMWare AirWatch, Wavelink
Avalanche, 42Gears SureMDM
Terminal Emulation StayLinked SmartTE, Wavelink Velocity

Datalogic Memor 10 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	720 x 1280 pixels
RFID reader	-
Certification	EU RoHS
Product color	Black
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Intelligent Mail, Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Data network	LTE
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Operating frequency	2400 / 5000 MHz
Operating system version	8.1
Operating system installed	Android
Internal memory	0.032 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Number of cores	8
Processor frequency	2 GHz
Second camera	No
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery voltage	3.8 V
Battery capacity	4100 mAh
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.7 mm
Width	78 mm
Height	155 mm
Weight	285 g
