Datalogic Memor X3 User Manual

1 MEMOR™ X3
108
5
READING OPTIONS
LASER CHARACTERISTICS
SCANNING RATE
BIDIRECTIONAL
104 ± 12 scan/sec
OPTICAL RESOLUTION 0.10 mm / 4 mils
SKEW ANGLE ± 50°
PITCH ANGLE ± 65°
LASER READER VLD, wavelength 630~680 nm
BAR CODES
UPC A, UPC E, EAN 8, EAN 13, Code 39, Code
39 Full ASCII, Code 32, Interleaved 2 of 5,
Industrial 2 of 5, Matrix 2 of 5,
Code 128, EAN
128, Codabar, MSI, Plessey, Code 93, Code 11,
GS1 Databar
LASER CLASSIFICATION
Laser: Class 2
Safety class EN 60825-1:2001
LED CLASSIFICATION Led (Green Spot): Class 1

Datalogic Memor X3 Specifications

General

Display Size	2.4 inches
RAM	256 MB
Processor	XScale PXA310 @ 806 MHz
Storage	512 MB
Operating System	Windows CE 6.0
Battery Capacity	1430 mAh
Connectivity	Wi-Fi, Bluetooth v2.1
Scanner	2D Imager
Battery Options	Standard and High Capacity
Protection	IP54
Drop Specification	Withstands drops from 1.2 meters
Operating Temperature	-10 to 50 °C
Storage Temperature	-20 to 70 °C
