4.6.3 FTP Server Setup
The Memor X3 Windows CE Operating System includes a sample File Transfer
Protocol (FTP) server. FTP is used for copying files to and from remote computer
systems over a network using TCP/IP. You can establish a connection to your
Memor X3 using its FTP Server through the WLAN interface.
Proceed as follows:
1. Create a registry file (extension .reg) to setup and enable FTP Server
communication. A simple example file for anonymous logon is given below:
REGEDIT4
[HKEY_LOCAL_MACHINE\Comm\FTPD]
"DefaultDir"="\\"
"AllowAnonymousUpload"=dword:00000001
"UseAuthentication"=dword:00000000
"BaseDir"="\\"
"IsEnabled"=dword:00000001
"LogSize"=dword:00001000
"DebugOutputMask"=dword:00000017
"DebugOutputChannels"=dword:00000002
"IdleTimeout"=dword:0000012c
"AllowAnonymous"=dword:00000001
"AllowAnonymousVroots"=dword:00000001
2. Copy this file to the Memor X3 using ActiveSync
®
.
3. Launch the .reg file from the Memor X3.
4. Perform a warm boot on the Memor X3.
5. From the PC > Explorer address bar (or running an FTP Client from the PC),
enter the Memor X3 IP address.
For more information on FTP Client/Server connections
refer to the following web page:
http://msdn2.microsoft.com/en-
us/library/aa922316.aspx.
NOTE

Datalogic Memor X3 Specifications

General

Display Size	2.4 inches
RAM	256 MB
Processor	XScale PXA310 @ 806 MHz
Storage	512 MB
Operating System	Windows CE 6.0
Battery Capacity	1430 mAh
Connectivity	Wi-Fi, Bluetooth v2.1
Scanner	2D Imager
Battery Options	Standard and High Capacity
Protection	IP54
Drop Specification	Withstands drops from 1.2 meters
Operating Temperature	-10 to 50 °C
Storage Temperature	-20 to 70 °C
