Datalogic Memor X3 User Manual

1 MEMOR™ X3
18
3
The Single Dock can be connected to the host computer by any standard mini USB
cable.
Once the host computer has been turned on, insert the Memor X3 mobile computer
into the cradle.
Key:
A Host computer C Single Slot Dock
B Standard mini USB cable D Power Supply
Connection through the cradle complies to USB 2.0 standard.
NOTE
The actual data transfer speed can be appreciably lower than the
maximum theoretical speed.
NOTE
B
D
C
A

Datalogic Memor X3 Specifications

General

Display Size	2.4 inches
RAM	256 MB
Processor	XScale PXA310 @ 806 MHz
Storage	512 MB
Operating System	Windows CE 6.0
Battery Capacity	1430 mAh
Connectivity	Wi-Fi, Bluetooth v2.1
Scanner	2D Imager
Battery Options	Standard and High Capacity
Protection	IP54
Drop Specification	Withstands drops from 1.2 meters
Operating Temperature	-10 to 50 °C
Storage Temperature	-20 to 70 °C
