Global Prefix/Suffix
Product Reference Guide 103
5. If less than the expected string of 20 characters are selected, scan the ENTER/
EXIT barcode to terminate the string.
6. Scan the ENTER/EXIT barcode once again to exit Programming Mode.
7. The resulting message string would appear as follows:
Scanned barcode data:12345
Resulting message string output: $12345
This option sets up to 20 characters each from the set of ASCII characters or any hex val-
ue from 00 to FF. To configure this feature, scan the ENTER/EXIT barcode to place the
unit in Programming Mode, then the “Set Global Prefix” or “Set Global Suffix,” barcode
followed by the digits (in hex) from the Alphanumeric characters in
Appendix E, Key-
pad
representing your desired character(s). If less than the expected string of 20 charac-
ters are selected, scan the ENTER/EXIT barcode to terminate the string. Reference the
section, Example: Setting a Prefix on page 102, for more information. Exit program-
ming mode by scanning the ENTER/EXIT barcode once again.
ENTER/EXIT PROGRAMMING MODE
Set Global Prefix
Set Global Suffix
Make a mistake? Scan the CANCEL barcode to abort and not
save the entry string. You can then start again at the beginning.
CANCEL
DEFAULT
No Global Prefix
Global Suffix = 0x0D (CR)
To Next Page
