Code 93

Product Reference Guide 307

Plessey — cont.

Plessey Character Correlation

Enables/disables Character Correlation for Plessey.

Code 93

The following options apply to the Code 93 symbology.

Code 93 Enable/Disable

Enables/Disables ability of reader to decode Code 93 labels.

ENTER/EXIT PROGRAMMING MODE

Plessey Character Correlation = Disable

Plessey Character Correlation = Enable

DEFAULT

ENTER/EXIT PROGRAMMING MODE

Code 93 = Disable

Code 93 = Enable

DEFAULT
