To Next Page

To Previous Page

Scanning Features

Product Reference Guide 33

Stand Mode Triggered Timeout

This feature specifies the time to remain in Trigger Single mode after the trigger is pulled

while in Stand Mode.

NOTE

This timeout is only used when the Scan Mode is configured as

Stand

Mode.

ENTER/EXIT PROGRAMMING MODE

Stand Mode Triggered Timeout = 0.5 Seconds

Stand Mode Triggered Timeout = 1.5 Seconds

Stand Mode Triggered Timeout = 2 Seconds

Stand Mode Triggered Timeout = 3 Seconds

Stand Mode Triggered Timeout = 4 Seconds

DEFAULT

Default Chapter3
