Datalogic PowerScan PM9500

To Next Page

To Previous Page

$CADUT12(CR)

Optional GS1-128 Add-On Timer = 180ms

$CADUT14(CR)

Optional GS1-128 Add-On Timer = 200ms

$CADUT16(CR)

Optional GS1-128 Add-On Timer = 220ms

$CADUT18(CR)

Optional GS1-128 Add-On Timer = 240ms

$CADUT1A(CR)

Optional GS1-128 Add-On Timer = 260ms

$CADUT1C(CR)

Optional GS1-128 Add-On Timer = 280ms

$CADUT1E(CR)

Optional GS1-128 Add-On Timer = 300ms
