Setup
12
PowerScan™ PD9530/PBT9500/PM9500
Attaching the Metal Plate to Base
Alternatively, the mount can be attached first to the base, then both can be
mounted to a wall as described above.
Figure 5. Attaching Mounting Plate to Base
System Connections
CAUTION
Connections should always be made with power off!
The BC9xx0 cradle provides a multi-interface connector and a power supply
connector as shown:
