Enter/Exit Programming Mode
Product Reference Guide
241
RS-485 Master Header/Terminator ( Prefix/Suffix)
Specifies the Master Cradle header or terminator characters to be added to a
label sent to Host. The characters may be added as a prefix (in a position
before the bar code data, also called a header) and/or as a suffix (in a posi-
tion following the bar code dat
a
, also called a terminator).
To configure this feature, scan the ENTER/EXIT PROGRAMMING MODE bar
co
de above to place the unit in Programming Mode, then the “Set Master
Cradle Prefix” or “Set Master Cradle Suffix” bar code followed by the digits
(in hex) from the Alphanumeric characters in
Appendix D, Keypad repre-
senting your desired character(s).
If less than the expected string of 8 char-
acters are selected, scan the ENTER/EXIT bar code
to terminate the string.
Exit programming mode by scanning the ENTER/EXIT bar code again.
Set Cradle Address
To configure this feature, scan the ENTER/EXIT PROGRAM-
MING MODE bar code above, then th
e bar code at left fol-
lowed by the digits from the Alphanumeric characters in
Appendix D, Keypad
representing your desired char-
acter(s). End by scanning the ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
