CONFIGURE ACTIONS FOR FUNCTION KEYS
Each of the function keys can be programmed to perform a user-assigned
function. This is done by associating a function key with either a predefined
command or your own custom string. See the "
Defin
e Strings" on page
25
1
command to define customized strings.
Each function key has an associated la
bel
which shows in the display when
active. The default labels are shown in the table below. To program the
function key labels, see "
Set S
tring ID" on page 252
.
T
he following table shows the list of predefined commands and available
stri
ngs.
Table 26. Keyboard Programming
CMD_ID Name Function
Default
Label
0 Not configured
No configured action.
If a key must be kept enabled but in normal mode isn’t
requir
ed, this function can be selected to keep it inactive.
Whenever an unconfigured function key is pressed, an error
message appears on display and an error beep is emitted.
<None>
1 Enter CMD Same as ENTER_KEY. Ent
2 String 1 Display and transmit string 1. S1T
3 String 2 Display and transmit string 2. S2T
4 String 3 Display and transmit string 3. S3T
5 String 4 Display and transmit string 4. S4T
6 String 5 Display and transmit string 5. S5T
7 Backlight CMD Toggle backlight on/off. Blt
8 Clear CMD Clears the screen CLR
9 Reserved for future use
A Reserved for future use
B Show Date/Time Display the internal date, time. Tim
C Reserved for future use

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
