Datalogic PowerScan PM9500 User Manual

Imager Labeling
Product Reference Guide 301
Imager Labeling
Sample labels are shown for illustrative purposes only. Please view the labels
on your product for actual detail
s, as they may vary from those depicted.
Scanner Regulatory Label
PM9500
Frequency working
center
910MHz 433MHz
Programmable
Spee
d
40 kb/s
100 kb/s
500 kb/s (default)
19.2 kb/s
100 kb/s
500 kb/s (default)
Typical Range (in
open air)
100m
from 50m
(at 500 kb/s)
to 100m
(at 19.2kb/s)
Max number of
devi
ces per base
station
16

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
