PowerScan™ PD9530/PBT9500/PM9500
Table 38
STEP ACTION EXAMPLES
1.
Scan the ENTER/EXIT bar
code
(Scanner enters Programming Mode)
2.
Determine placement of
the
Label ID characters
BEFORE or AFTER with
regard to scanned data
using
Label ID
Control, starting on page
56
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting
the
symbology type you
wish to designate label ID
characters for using Label
ID Symbology Selection −
1D Symbologies, starting
on page 57
.
DataBar
Omnidirectional
Code 39
Interleaved 2 of
5
Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from
the
ASCII Chart(inside
back cover), then scan in
thes
e digits/characters
using the bar codes in the
section: Keypad, starting
on page 323
. If you make
a mistake before the last
character, scan the CANCEL
bar code to abort and not
save the entry string. You
can then start again at the
beginning.
44 42 2A 3D 43 33 2B 50 48
6.
Scan the ENTER/EXIT bar
code
(Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT bar
code once
again
(Scanner exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code data] [bar code data]PH
. Label ID Examples
To Next Page
