QUICKSCAN
®
MOBILE
148
READER DATA ENTRY
Beeper¹
LED Meaning
one beep²
ON Correct read of a code in normal mode
H L long TX buffer full (when FIFO is enabled) or TX error
between QuickScan
®
Mobile and
the cradle
H long ON Successful advanced format concatenation
H H H Timeout expired – operation not completed
H H long Error in advanced data formatting
OFF Ready to read a code
READER POWER
Beeper LED Meaning
10 short H 10 short blinks Low Battery
READER BIND AND JOIN
Beeper¹
LED Meaning
Blinking Command accepted; reader ready to be inserted into
the cradle
L Success
H L long
tones
Failure
¹ Only the Beeper Intensity command can modify these signals.
² The data entry good read tone is user-configurable with all
the Beeper commands
in the Reading Parameters section.
Normally this results in two beeps; the first indicates that the reader has decoded
the code, the second indicates whether the cradle has received the data. See also
par. 4.7.3.
