INSTALLATION
3
2 INSTALLATION
2.1 USING YOUR QUICKSCAN
®
MOBILE READING SYSTEM
Follow the procedure below to start using your QuickScan
®
Mobile reading system:
1. Connect a QuickScan
®
Mobile cradle to the Host.
2. Insert the QuickScan
®
Mobile reader into the cradle to start the battery charging.
A full charge of the Lithium battery takes 3.5 – 6 hours.
NOTE
To achieve the best battery life, it is recommended to perform a full
battery charge before using the reader
in hand-held mode
.
In hands-free use, you can immediately start using the reader, since it is
powered by the cradle.
3. Configure the QuickScan
®
Mobile reader.
4. Configure the QuickScan
®
Mobile cradle.
2.2 CHANGING THE BATTERIES
To change the battery of your reader, you must:
1. Unscrew the battery cover screw (Figure 1).
2.
Unplug the wh
ite connector and remove the old battery (Figure 2).
3. Insert the new battery
and plug in the white connector.
NOTE
When inserting the new battery into the handle pay attention to
position the battery and the connector just as shown in Figure 3.
Figure 1 Figure 2 Figure 3
