Datalogic QuickScan Mobile User Manual

QUICKSCAN
®
MOBILE
152
RS-232
DESCRIPTION STRING
Baud rate 300
CD1
600
CD2
1200
CD3
2400
CD4
4800
CD5
9600
CD6
19200
CD7
38400
CD8
Parity none
CC0
even
CC1
odd
CC2
Data bits 7
CA0
8
CA1
9
CA2
Stop bits 1
CB0
2
CB1
Handshaking disable
CE0
RTS/CTS
CE1
XON/XOFF
CE2
RTS always On
CE3
ACK/NACK Protocol disable
ER0
enable
ER1
FIFO disable
EC0
enable
EC1
Inter-character delay (ms)
CK00 - CK99
RX Timeout (100 ms)
CL00 - CL99
disable
CR0
Serial Trigger Lock
enable and select characters
CR1
ab
a = Hex values representing an ASCII character from 00 to FE enabling the device trigger.
b = HEX values representing an ASCII character from 00 to FE inhibiting the device trigger.
