CONNECTIONS
USER’S MANUAL
95
USB Dock Connection
1. Turn on the host computer.
2. Connect the single slot dock full to the power supply (available as an accessory, p/
n 91AC
C0048).
3. Connect the single slot dock full to the host computer by means of a standard USB
Ty
pe
A to Type-C cable.
4. Turn on the Skorpio X5.
5. Insert the Skorpio X5 into the dock.
Host Computer
Power Supply
(P/N 91ACC0048)
Single Slot Dock
USB Type A to Type-C Cable
NOTE: When the device is inserted into the dock, all ongoing USB connec-
tions shall be kept until the corresponding port is unplugged.
To Next Page
