H-Class 121
Printing
Method: Direct Thermal or (optional) Thermal Transfer
Speed: 2 - 12 IPS (51 - 305 mmps); H-4212X
2 - 10 IPS (51 - 254 mmps); H-4310X
2 - 6 IPS (51 - 152 mmps); H-4606X
Resolution: 203 DPI (8 dots/mm); H-4212X
300 DPI (12 dots/mm); H-4310X
600 DPI (23.6 dots/mm); H-4606X
Dot Size (nominal): .0043" X .0052" (.11 mm x .13 mm); H-4212X
.0027" X .0043" (.07 mm x .11 mm); H-4310X
.0008" X .0015" (.02 mm x .04 mm); H-4606X
Tear Bar: Downward tear
Media
Types: Die-Cut, Notched, Continuous, and Reflective
(Roll or Fanfold)
Internal Capacity: 8-inch (203mm) Outer Diameter Roll (on a standard 3-inch
core; or, on a 40 mm core with the optional supply hub)
Ribbon Width Range: 1 inch - 4.65 inches (25 mm – 118 mm)
Ribbon Length: 1968 feet (600 m)
Dimensions: Reference the drawing and table below:
E
J
I
C
K
A
B
D
H
F
G
Side View
Top View
To Next Page
