122 H-Class
Media (continued)
H-4212X, H-4310X, & H-4606X Media Dimensional Requirements
[1]
Minimum
Maximum
Designator Description
inches mm inches mm
A Label width 1.00 25 4.65 118
B Liner width 1.00 25 4.65 118
C Gap (or notch) between labels
[3]
.08 2 – –
D Label length
[3]
.25 6 – –
E Media thickness .0025 .06 .01 .25
F Notch opening width .08 2 – –
G Media edge to sensor aperture .20 5 2.25 70
H Reflective mark width
[2]
.47 12 4.65 118
I Distance between reflective marks
[3]
.25 6 – –
J Reflective mark length
[3]
.08 2 – –
K Label repeat distance
[3]
.33 8 – –
[1]
Units of measure are referenced by the direction of label feed.
[2]
The reflective (black) mark must be carbon based, placed on the backside of the stock, and the
reflectance shall be less than 10% at wavelengths of 950 and 640 nm.
[3]
The maximum allowable length of the combined label and gap (or mark) measurement cannot
exceed 99.99 inches.
H-6210 & H-6308 Models
Mechanical
Height: 13 inches (329.7 mm)
Width: 15 inches (381 mm)
Depth: 18.9 inches (480.1 mm)
Weight: 47 pounds (21.3 kg)
Electrical
Display: Graphics (128 X 64 pixels) with backlight; or
(Optional) Graphics (240 X 320 pixels) with backlight.
