H-Class 123
Printing
Method: Direct Thermal or (optional) Thermal Transfer
Speed: 2 - 10 IPS (51 - 254 mmps); H-6210
2 - 8 IPS (51 - 203 mmps); H-6308
Resolution: 203 DPI (8 dots/mm); H-6210
300 DPI (12 dots/mm); H-6308
Dot Size (nominal): .0043" X .0052" (.11 mm x .13 mm); H-6210
.0027" X .0043" (.07 mm x .11 mm); H-6308
Tear Bar: Downward tear
Media
Types: Die-Cut, Notched, Continuous, and Reflective
(Roll or Fanfold)
Internal Capacity: 8-inch (203mm) Outer Diameter Roll (on a standard 3-inch
core; or, on a 40 mm core with the optional supply hub)
Ribbon Width Range: 2 inches - 6.7 inches (51 mm – 170 mm)
Ribbon Length: 1968 feet (600 m)
Dimensions: Reference the drawing and table below:
E
J
I
C
K
A
B
D
H
F
G
Side View
Top View
