H-Class 69
Diagnostics (continued)
Menu Item Details
TEST SCANNER
Tests the Linear Scanner, where:
ALIGNMENT TEST
Enters multiple read mode, decoding bar codes where
a count is displayed and incremented for each decode.
SCAN TEST
Enters single read mode, decoding a bar code then
displaying the results.
TEST RFID
Tests RFID, where:
TAG DATA
Reads the data encoded on an RFID tag.
DEVICE VERSION
Displays the type and version of the encoding device.
TAG ID – HF ONLY
Reads then displays the High Frequency Tag ID
number.
PRINT TEST RATE (min)
Allows a label-to-label delay (0 - 120 minutes) when
batch printing Test Labels, where:
000 (0 – 120)
Is the selected delay interval, in minutes.
SENSOR READINGS
Displays various sensor values (0 – 255), where:
THR TRAN RIBM 24V
127 159 093 175
PS HD RANK
000 254 125
Are readings for the printhead thermistor sensor
(THR), media “gap” sensor (TRAN) or “reflective”
sensor (REFL), ribbon sensor (RIBM), 24VDC power
supply sensor (24V), present sensor (PS), printhead
assembly sensor (HD) and, printhead ranking resistor
(RANK). (The values given here are examples only.)
RIBBON SENSOR LIMITS
Displays ribbon sensor values for thermal transfer
equipped printers, where:
RIBBON ADC LOW
9
RIBBON ADC HIGH
250
Are the sensor readings. (The values given here are
examples only.)
