1-7
001-4006-101
1.11 CONFIGURATION
1.11.1 T-96SR FIELD PROGRAMMING SOFTWARE
Operating characteristics of the T-96SR are configured by the Field Programming Software. Offline
Diagnostics and Online Diagnostics give access to Offline Diagnostics and commands (local and remote)
and online diagnostics monitoring (with or without a T-Base/R). Programming software is Windows
® based
and requires a Windows 95 or better operating system. Context sensitive help and printable help files are
provided with this program.
The T-96SR requires the use of the Field Programming Software for configuration, adjustment and
diagnostics.
1.11.2 DIAGNOSTICS AND REMOTE COMMANDS
Diagnostics and remote commands are processed using the T-96SR Offline diagnostics utility. Diagnostics
can be monitored using the T-96SR Online Diagnostics utility.
1.11.3 ADDRESSING
Each T-96SR has addressing capability which is used for diagnostics and remote commands only.
Table 1-3 Diagnostics and Commands
Online Diagnostics Information is automatically sent by each
unit at the beginning of every transmission.
May be disabled for back compatibility with
Dataradio T-Modem 96 or Motorola RNet
9600
Offline Diagnostics Information is sent by a specific unit in
response to an inquiry by the master or
monitoring station
Remote Commands Commands may be sent by the master or
monitoring station to any specific remote unit
Table 1-4 T-96SR Addresses
ID Number This value (maximum 1023) is assigned at the factory but may be
modified using the Field Programming Software. The ID Number
is used to uniquely identify the T-96SR for remote commands and
Offline Diagnostics. The ID Number may have values within the
range of 1 to 4294967295 but multiples of 1024 should not be
used
Short ID This value (maximum 1023) is the low order 10 bits of the ID
Number. It is used to identify online diagnostics only. It may not
be modified directly using the Field Programming Software; it is
always derived from the ID Number. All units within a network
should have unique Short ID numbers to avoid ambiguity in
Online Diagnostics reports.
