Dataradio T-96SR - General Specifications

1-12
001-4006-101
T-96SR General Specifications
The following general specifications are subject to change without notice.
* per TIA 603 with psophometrically weighted filter
*
GENERAL
VHF UHF 900 MHz
Frequency 132 - 174 MHz 380 - 512 MHz 928 - 960 MHz
Channel bandwidth 12.5 or 25 kHz 12.5 or 25 kHz 12.5 or 25 kHz
Operating temperature -30°C to +60°C
Supply voltage 10 - 16 VDC (applied through the interface connector)
RX Current at 13.3 VDC 150 mA 125 mA 135 mA
TX Current at 13.3 VDC 2.1 A 2.5 A 2.8 A
RX/TX bandwidth 18 MHz (132 - 150)
24 MHz (150 - 174)
16 MHz except
20 MHz (450 - 470)
32 MHz
Nominal Dimensions 2.212” (H) x 3.25” (W) x 4.585” (L)
Shipping Weight 1.20 lbs (0.55 Kg)
RF connector SMA-F
Interface connector DE-15F high density D-subminiature
RECEIVER
VHF UHF 900 MHz
Selectivity (25 kHz)
70 dB minimum 65 dB minimum
Selectivity (12.5 kHz)
60 dB minimum 70 dB minimum
Intermodulation
70 dB minimum 60 dB minimum
Spurious rejection
70 dB minimum 70 dB minimum
Conducted spurious < -57 dBm maximum
-57 dB max
TRANSMITTER
VHF UHF 900 MHz
Power output 1 - 5 watts 1 - 5 watts 1 - 5 watts
Spurious and harmonics -73dBc (-36 dBm) max -73dBc (-36 dBm) max -57 dBc (-20 dBm) max
Frequency stability 2.5 ppm
1.5 ppm
Duty cycle 50% at full power, 30 seconds maximum transmit time
* per TIA 603 with psophometrically weighted filter
*
