2-5
001-4006-101
2.4 CHANNEL SELECTION
Channel frequencies for 8 channels are programmed using the T-96SR Field Programming Software (FPS).
Once programmed, the current operating channel may be selected either by:
1.Utilizing hardware jumpers By strapping connections on the Data Port Connector. There is a 10k ohm pull
up resistor on each line (CS0 to CS2) (refer to Table 2-5) or making changes with the T-96SR Field
Programming Software:
2.By selecting the channel from the T-96SR FPS Offline Diagnostics feature.
Table 2-5 Channel Selection
Channel CS2 CS1 CS0
1 gnd gnd gnd
2 gnd gnd open
3 gnd open gnd
4 gnd open open
5 open gnd gnd
6 open gnd open
7 open open gnd
8 open open open
