2-13
001-4006-101
Table 2-8 RTS/CTS Delays
Data Format
The Data Format field selects the word length and number of stop bits for the data stream. The following
options are available*:
a. 8 Data Bits, 1 Stop Bit
b. 8 Data Bits, 2 Stop Bits
c. 9 Data Bits, 1 Stop Bit
d. 9 Data Bits, 2 Stop Bits
Table 2-8 shows supported user formats and modem programming.
Note: A Yes in the Parity column indicates Even/Odd or Mark/Space Parity. A No in the Parity column
indicates none. N/A means the combination is not available.
Table 2-7 RS-232 Interface and Network Baud Rates
Configuration Baud Rates
Full-Channel T-96SR in “T-96SR Native” network type 4800, 9600, 19200
Half-Channel T-96SR in “T-96SR Native” network type 4800, 9600
Full-Channel T-96SR in “T-96S/DL3276” network type 4800, 9600
Half-Channel T-96SR in “T-96S/DL3276” network type 4800
Full-Channel T-96S 1200, 2400, 4800, 9600
Table 2-9 Supported User Formats and Modem Programming
Data Bits Parity Stop Bits Modem*
7No1N/A
7Yes1a
7No2a
7Yes2b
8No1a
8Yes1b or c
8 No 2 b or c
8Yes2d
9No1c
9Yes1d
9No2d
9 Yes 2 N/A
RTS/CTS delay (normal) RTS/CTS delay (extended)
Product Mode
Speed diag. off diag. on diag. off diag. on
T-96S 4800 b/s 30 ms 54 ms 60 ms 85 ms
T-96S 9600 b/s 30 ms 41 ms 60 ms 75 ms
T-96SR 9600 b/s 20 ms 32 ms 40 ms 55 ms
T-96SR 19200 b/s 20 ms 28 ms 40 ms 50 ms
