SECTION 1
GENERAL INFORMATION
1-1
001-4006-101
1.1 INTRODUCTION
1.1.1 GENERAL
This installation manual provides information for selecting, installing, operating, and maintaining the
Dataradio T-96SR wireless modem.
1.2 FEATURES
The T-96SR is a transparent real-time wireless modem designed primarily for SCADA (Supervisory Control
and Data Acquisition) and telemetry use. Features of the T-96SR include:
z Data speeds of 4800 to 19200 b/s (9600 b/s maximum in half-channels) using a standard RS-232 interface
z Built-in 8 channel synthesized radio transceiver for VHF and UHF bands
z Power output of 1 W to 5 W (software controlled)
z Half duplex or simplex operation
z Transmit control via RTS
z Online diagnostics monitoring
z Offline local and remote diagnostics
z Compatible with Dataradio T-Base for base station or repeater use
z Compatible with any Dataradio Interoperability Standard (DI-OS) equipment including the T-96S for data
rates of 4800 and 9600 b/s.
1.3 T-96SR PART NUMBER BREAKDOWN
The following table shows the breakdown of the T-96SR part number.
Table 1-1 T-96SR Part Number Breakdown
242-40W6-XYZ(F)*
W X Y Z (UHF units) F (optional)
1 VHF 0 406-430 MHz 1 12.5 kHz 0 406-422 MHz Fan option
4 UHF 1 380-403 MHz 3 25 kHz 1 414-430 MHz
2 403-419 MHz
3 419-435 MHz
4 132-150 MHz (VHF), 435-451 MHz (UHF)
5 450-470 MHz (UHF)
6 150-174 MHz (VHF), 464-480 MHz (UHF)
7 480-496 MHz
8 496-512 MHz
