1-13
001-4006-101
*Subject to change.
MODEM OPERATION
Interface EIA RS-232C
Operation Simplex/half duplex
Data rates 12.5 KHz Channels 4800, 9600 bps
25 KHz Channels 4800, 9600, 19200 bps
Modulation type DRCMSK
RTS/CTS delay
(Online diagnostics OFF)
30 ms
Bit error rate
better than 1 x 10
–
5
at 1.0 µV at 9600 b/s half channel
better than 1 x 10
–
6
at 1.0 µV at 9600 and 4800 b/s full channel
better than 2 x 10
–
5
at 1.7 µV at 19200 b/s full channel
Protocol Transparent to the user
DISPLAY and CONTROLS
3 status LEDs RX, TX, PWR
DIAGNOSTICS
Online Supply voltage, internal temperature, forward and reverse power, RSSI
Offline As for online, plus analog supply voltage, transmit test tones
PROGRAMMABLE FEATURES
30 second timeout timer enable, bit rate, word length, parity, compatibility modes, frequency, channel, diagnostics on/off.
FCC / IC
CERTIFICATIONS
FCC IC (DOC)
VHF 2424016-001 2984195430A
(9K30F1D)
(15K3F1D)
(15K0F1D)
(16K0F1D)
(11K0F1D)
(9K30F1D)
UHF
2424046-001
(9K30F1D)
(15K3F1D)
2984195432A
(9K30F1D)
(11K0F1D)
(15K3F1D)
(16K0F1D)
900 MHz
2424096-001
(9K30F1D)
(15K3F1D)
2984195431A
(9K30F1D)
(11K0F1D)
(15K3F1D)
(16K0F1D)
*
