USER INTERFACE DIALOGUE
44 SH4 BASE-STANDARD
RX Side dialogue
ESPE
WORKING MODE
INDICATION LED CONFIGURATION
Alignment
Not aligned
Aligned
Minimum Signal Level
Aligned
Medium Signal Level
Aligned
Maximum Signal Level
Module signal status
(from 2
nd
module)
Good Signal on
modules, no optics
intercepted
Low Signal on
modules, no optics
intercepted
At least one optic
intercepted on
modules with
blinking red light
(eg.) Modules with
different signal
levels
Normal Operation
Manual Restart Only
Manual Restart
configured
Interlock, free
beams, restart
required
Normal Operation EDM Active
Normal Operation
OSSD OFF
NO CODE
1
st
module
2
nd
module
N
th
module
