ACCESSORIES
74
SH4 BASE-STANDARD
MIRRORS
Deviating mirrors
Figure 17 - Deviating mirrors (mm)
Figure 18 - SG-DM 150 (mm)
MODEL DESCRIPTION L1 (mm) L2 (mm) L3 (mm) CODE
SG-DM 600 Deviating mirror version 600 mm 545 376 580 95ASE1680
SG-DM 900 Deviating mirror version 900 mm 845 676 880 95ASE1690
SG-DM 1200 Deviating mirror version 1200 mm 1145 976 1180 95ASE1700
SG-DM 1650 Deviating mirror version 1650 mm 1595 1426 1630 95ASE1710
SG-DM 1900 Deviating mirror version 1900 mm 1845 1676 1880 95ASE1720
NOTE: The image includes the mirror SG-DM and a mounting kit ST-DM.
MODEL DESCRIPTION CODE
SG-DM 150 Deviating mirror version 150 mm 95ASE1670
NOTE: The image includes the mirror SG-DM and a mounting kit ST-DM.
