RESPONSE TIMES
PRODUCT REFERENCE GUIDE 59
Pairing table
RESPONSE TIMES
Next tables resumes the response time values of every SH4 models related to the num-
ber of beams and the protected height.
The response time is a function of the protected height, the resolution of the light cur-
tain and Anti Interference Coding (AIC) selection.
SH4-14-XXXX-X-X models
SH4-30-XXXX-X-X models
PAIR MODEL RECEIVER MODEL EMITTER MODEL
SH4-14-XXXX-B-5 SH4-14-XXXX-B-R-5 SH4-14-XXXX-T-5
SH4-14-XXXX-S-8 SH4-14-XXXX-S-R-8 SH4-14-XXXX-T-5
SH4-30-XXXX-B-5 SH4-30-XXXX-B-R-5 SH4-30-XXXX-T-5
SH4-30-XXXX-S-8
SH4-30-XXXX-S-R-8 SH4-30-XXXX-T-5
SH4-2/3/4-XXXX-B-5 SH4-2/3/4-XXXX-B-R-5 SH4-2/3/4-XXXX-T-5
SH4-2/3/4-XXXX-S-8 SH4-2/3/4-XXXX-S-R-8 SH4-2/3/4-XXXX-T-5
MODEL
PROTECTED
HEIGHT (mm)
NO. BEAMS
RESPONSE TIME
(ms)
AIC DISABLE
RESPONSE TIME
(ms)
AIC ENABLE
SH4-14-0300-x-x 300 30 9 14
SH4-14-0450-x-x 450 45 10 18
SH4-14-0600-x-x 600 60 12 22
SH4-14-0750-x-x 750 75 13 26
SH4-14-0900-x-x 900 90 15 30
SH4-14-1050-x-x 1050 105 16 33
SH4-14-1200-x-x 1200 120 18 37
SH4-14-1350-x-x 1350 135 20 41
SH4-14-1500-x-x 1500 150 21 45
SH4-14-1650-x-x 1650 165 23 49
SH4-14-1800-x-x 1800 180 24 52
SH4-14-1950-x-x 1950 195 26 56
SH4-14-2100-x-x 2100 210 27 60
SH4-14-2250-x-x 2250 225 29 64
MODEL
CONTROLLED
HEIGHT (mm)
NO. BEAMS
RESPONSE TIME
(ms)
AIC DISABLE
RESPONSE TIME
(ms)
AIC ENABLE
SH4-30-0300-x-x 300 12 7 10
SH4-30-0450-x-x 450 18 8 12
SH4-30-0600-x-x 600 24 9 13
SH4-30-0750-x-x 750 30 9 15
SH4-30-0900-x-x 900 36 10 17
SH4-30-1050-x-x 1050 42 11 18
SH4-30-1200-x-x 1200 48 12 20
