BRACKETS
PRODUCT REFERENCE GUIDE
69
Angled fixing bracket mounting with orientable and anti-vibration
supports
Figure 7 - Angled fixing bracket
Figure 8 - Angled fixing bracket + Orientable support
Figure 9 - Angled fixing bracket + Anti-vibration support
Figure 10 - Angled fixing bracket + Orientable support + Anti-vibration support
MODEL DESCRIPTION CODE
ST-K4OR Orientable supports (4 pcs kit) 95ACC1680
ST-K6OR Orientable supports (6 pcs kit) 95ACC1690
ST-K4AV Anti-vibration supports (4 pcs kit) 95ACC1700
ST-K6AV Anti-vibration supports (6 pcs kit) 95ACC1710
NOTE: Dimensions are in mm.
