SH4 BASE-STANDARD
CHAPTER 3
MECHANICAL MOUNTING
The emitting (TX) and receiving (RX) units must be installed with the relevant sensitive
surfaces facing each other.
The connectors must be positioned on the same side and the distance must be included
within the operating range of the model used (see appendix “Technical Data”).
The two units must be positioned the most aligned and parallel possible.
The next step is the fine alignment, as shown in the chapter “Alignment Procedure”.
Outfit angled fixing brackets kit for units mounting must be used as described below
(see Figure 17).
Adjustable supports for adjusting unit inclinations around the axes are available on
request (see appendix “Accessories”).
