SAFETY UNITS
Safety unit
The drawing shows the connection between the safety light curtain and the Type 4
safety relay of the SE-SR2 series operating in the automatic Restart mode.
Figure 22 - Safety relay
EDM relay box
Figure 23 - EMD relay
MODEL DESCRIPTION CODE
SE-SR2 Type 4 safety relay - 3 NQ 1 NC 95ACC6170
MODEL DESCRIPTION CODE
CSME-03VU24-Y14 EDM relay 95ASE1270
