Datasensing SH4 BASE-STANDARD - TX Connection

CONNECTION
PRODUCT REFERENCE GUIDE 85
TX connection
NOTE: See chapter “Connections” for consult the connector’s pin-out.
NOTE: A safe auto-recognition procedure at startup is implemented; it
automatically detects cascade topology and correctly address units.
M12 5 pin, male
M12 5 pin
female
M12 5 pin
male
M12 5 pin
female
M12 5 pin
male
M12 5 pin female or none
