Couple arms
The following figures show respectively the dimensions of single active arms with fixing
bracket mounted, of single passive arms with fixing bracket mounted, of double active
arms with fixing bracket mounted, and of double passive arms with fixing bracket
mounted.
SH-T-ARMS
SH-L-ARMS
MODEL DESCRIPTION CODE
SH-T-ARMS T COUPLE ARMS 95ASE0035
SH-L-ARMS L COUPLE ARMS 95ASE0036
