CASCADE SYSTEM
88 SH4 BASE-STANDARD
RX Side dialogue
ESPE
WORKING MODE
INDICATION LED CONFIGURATION
Normal Operation
Good Signal on
modules, no optics
intercepted
Low Signal on
modules, no optics
intercepted
At least one optic
intercepted on
modules with
blinking red light
(eg.) Modules with
different signal
levels
Minimum Signal
Level
Maximum Signal
Level
Normal Operation
OSSD OFF
Invalid Blanking
(current unit) or
Muting Active or
Override Active
On models longer than 1200 only even modules blinking yellow
Blanking on current
unit Active
Configuration
GUI Configuration
Pending
Failure Lockout
Slave units only show their
error code
F22
Microprocessor
Failure
F33
Optics Failure
F1122
Cascade Failure
1
st
module
2
nd
module
N
th
module
