Davis Instruments Vantage VUE Console Manual

Displaying Weather Variables
25
Evapotranspiration (ET) (Optional)
All the evapotranspiration
values share the same section
on the console as rain values,
below the barometric
pressure variable, on the right
side.
Note: Evapotranspiration, solar radiation and UV index measurements are available only when
the Vantage Vue console is listening to a Vantage Pro2 Plus ISS or other Vantage Pro2
ISS in which a solar radiation (and a UV sensor, for UV index) has been installed and
“VP2 ISS” has been selected in Screen 6 of the Setup Mode. See “Screen 6: Configuring
Transmitter IDs” on page 9.
1. Press and release 2ND then press ET to display the daily
evapotranspiration reading.
Note: If you hear an error beep when selecting ET, it means the station the console is selected
to “hear” is not a Vantage Pro2 station with a solar radiation sensor.
2. Press and release 2ND then press ET again to display the monthly
evapotranspiration reading.
3. Press and release 2ND then press ET a third time to display the
evapotranspiration reading since January 1st of the current year.
4. Press WxCEN to display the weather information available for all of the ET
variables in the Weather Center.
5. Press WxCEN multiple times to scroll through the ET-related Weather
Center screens, which include:
• ET Last __ Days — Displays the total ET amount over a user-selected
number of days. To change the number of days over which the total ET
amount is displayed, press the + and - keys when this screen is displayed
in the Weather Center. The number of days allowable is 26 (the last 25
days plus the current day).
• Solar Radiation — Displays the current solar radiation measurement for
the day.
• UV Index — Displays the current UV index.
Weather Center
Press WxCEN to view added information in the Weather
Center section of the console for each variable. See each
individual variable for a list of Weather Center screens available
for each variable.
in
ET DAY
S
SESW
MPH
WIND
HEAT
F
Daily Evapotranspiration with Solar Radiation
information displayed in the Weather Center
ET
RAIN
2ND
W
XCEN

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
