Davis Instruments Vantage VUE Console Manual

52
Vantage Vue Console Icons
Console icons indicate weather conditions and special functions.
Forecast
Forecast icons show what weather conditions may occur for the next 12 hours.
Moon Phase
Shows the current moon phase. Sequence shown for Northern Hemisphere. The sequence of
the icons is reversed in the Southern Hemisphere.
Alarm Bell
Flashes when an alarm is triggered. Indicates when the console is in Alarm
Mode.
Graph
Appears next to the currently selected weather variable. Indicates the graphed
variable on most screens.
Second Function
Appears when you press 2ND . Indicates that console key secondary func-
tions are enabled.
Rain
Appears when the ISS is currently detecting rain.
Barometric Pressure Trend
Arrows show direction of pressure change for last three hours.
Contacting Davis Technical Support
If you have any questions or encounter problems installing or operating your
Vantage Vue weather station, contact Davis Technical Support. We’ll be glad to help.
(510) 732-7814 — Monday - Friday, 7:00 a.m. - 5:30 p.m. Pacific Time. We are unable to
accept collect calls.
(510) 670-0589 — Technical Support Fax.
support@davisnet.com — E-mail to Technical Support.
info@davisnet.com — General e-mail.
www.davisnet.com — Davis Instruments web site.
See the Weather Support section of our website for copies of user manuals, product
specifications, application notes, and information on software updates. Watch for
FAQs and other updates.
Mostly Clear Partly Cloudy Mostly Cloudy SnowRain
New
Moon
First
Quarter
Full
Moon
Last
Quarter
New
Moon
Waxing
Crescent
Waning
Crescent
Waxing
Gibbous
Waning
Gibbous
2
nd

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
