Davis Instruments Vantage VUE Console Manual

Console Location
4
Installing the AC Power Adapter (Optional)
1. Find the power jack located on the left side of the
console case.
2. Insert the power adapter plug into the console
power jack, then plug the other end of the adapter
into an appropriate power outlet.
3. Check to make sure the console runs through a
brief self-test procedure successfully. See
“Installing Batteries” on page 3 for information on
the self-test procedure.
Note: When using an AC power adapter, be sure to use the power adapter supplied with your Vantage
Vue console. Your console may be damaged by connecting the wrong power adapter. You must
use AC power when using WeatherLinkIP.
Console Location
Place the console in a location where the keyboard is easily accessible and the display
is easy to read. For more accurate readings, follow these suggestions.
• Avoid placing the console in direct sunlight. This may cause erroneous inside
temperature and humidity readings and may damage the unit.
• Avoid placing the console near radiators or heating/air conditioning ducts.
• If you are mounting the console on a wall, choose an interior wall. Avoid exterior
walls that tend to heat up or cool down depending on the weather.
• Avoid positioning a wireless console near large metallic appliances such as
refrigerators, televisions, heaters, or air conditioners.
• The console antenna does not rotate in a complete circle. Avoid forcing the
console antenna when rotating it.
• Be aware of possible interference from cordless phones or other devices. To
prevent interference, maintain a distance of 10 feet (3 meters) between the
Vantage Vue console and a cordless phone (handset and base).
Plugging in the AC adapter

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
