CLEANING THE BURNERS
For proper lighting and performance keep the
burners clean. It is necessary to clean the burn-
ers if they do not light although the igniter
clicks, whenever there has been a severe boil
over or when the flame doesn’t burn blue.
Be certain all burner knobs are in the OFF posi-
tion before attempting to clean the burners. The
burners have been designed for ease of clean-
ing. When the grates and burners are cool, re-
move the grate. The Burner Cap and the Brass
Port Ring can easily be lifted off. Wash these
parts in hot soapy water, rinse and dry thor-
oughly. The Burner Caps are porcelain enamel,
follow the directions on page 23 that were
given to clean the burner grates. A bristle brush
can be used to clean out the toothed burner
ports, if necessary. Disassembly of the Simmer
Ring is not recommended, however, it may be-
come necessary to do so if the ports remain
clogged after normal cleaning. If it is necessary
to disassemble the Simmer Ring from the Base,
remove the Hex Nut at the top of the Simmer
Ring. Clean the Simmer Ring with hot soapy
water using a soft wire or plastic bristle brush
then dry thoroughly. Reassemble the parts us-
ing the Hex Nut.
After cleaning, it is important to make sure the
Locating Pin on the bottom side of the Simmer
Ring is properly aligned with the correspond-
ing hole in the Base and that the Locating Pin
(see insert) in the bottom side of the Brass Port
Ring is properly aligned with the Locating
Cap
Brass
Port Ring
Simmer
Ring
Base
Hex Nut
Brass Port
Ring
Locating Pin
Locating Pin
Locating
Notch
Locating
Pin Hole
Inside
Notch on the top side of the Simmer Ring. In-
correct alignment will produce a potentially
dangerous flame and poor burner performance.
Igniter
Cooktop Burner
CLEANING THE IGNITERS
Be certain all burner knobs are in the OFF posi-
tion before attempting to clean the igniters.
Gently wipe with a water dampened cotton
swab and be careful not to damage the igniter.
