PRELIMINARY
PARTS LIST
Key # Qty. Part # Description
1 4 12273 C Burner Cap
2 4 12271 C Port Ring
3 5 15219 Venturi Nut
4 4 12280 C Simmer Ring
5 5 13378 Venturi
6 4 12303 C Burner Base
7 5 12214 Electrode
7A 5 12211 Spring
8 5 12214 Clip
9 1 91957-01 AP Stainless Steel
9A 1 91957-08 PC AP White
9B 1 91957-07 PC AP Black
10 2 91592 Burner Hanger (L/R)
11 5 12150 Nut M22, Jet Holder
12 5 15185 Nut
13 1 91591 Box, Lower
14 10’ 14175 Foam Tape
15 4 12254-04 Jet Holder, Simmer C - LP
15A 5 12254-01 Jet Holder, Simmer C - Nat.
16 4 12200-07 Jet Holders, C12 K - Nat.
16A 4 12200-12 Jet Holders, C15 K - LP
17 16 15001-01 Screw, Phillips
18 1 91593 Burner Hanger (CTR)
19 4 91164 Bracket, Hold Down Kit
- 4 15117-02 Thumbscrew
- 4 15029 Nut W / Retainer
20 4 12254-01 Jet Holder D, Simmer - Nat.
20A 1 12254-02 Jet Holder D, Simmer - LP
21 1 12200-08 Jet Holder D , Main (CTR) - Nat.
21A 1 12254-02 Jet Holder D , Main (CTR) - LP
22 1 91807 Bracket (Optional)
23 1 16458 Re-Ignition Module (5PT)
24 2 15001-29 Screw
25 2 15005-22 Washer
26 - 15001-22 Screw
27 10 15003-33 Hex-Head Bolt
28 1 18329 Manifold
29 5 12177 Valve Clamp
30 5 18301-01 Compression Nut
31 1 91640 Plate, Nut
31A 1 15001-22 Screw, Ground
32 2 15005-22 Washer
33 2 15001-22 Screw
34 1 13340 Regulator
35 5 18301-02 Ferrule
36 5 12181 Clip
Key # Qty. Part # Description
37 4 13390-02 Valve, “C” - Nat.
37A 4 13390-03 Valve, “C” - LP
38 1 13390-06 Valve, “D” - Nat.
38A 1 13390-03 Valve, “D” - LP
39 5 16332 Switch GH-400-002-B2
40 1 14245 Bushing, Strain Relief
41 1 15217 Washer, Felt
42 2 15001-22 Screw
43 1 16464 Transformer
44 1 16005-03 Power Cord
45 1 91675 Bracket Connector
46 - 15001-22 Screw
47 5 91635 Bracket, Light
48 5 16421-01 Light Clip, DN
49A - 17266-01 Logo (Black or White Top)
50 1 14257-07 Bezel, Right Front
51 1 14257-06 Bezel, Right Rear
52 1 14257-05 Bezel, Center
53 1 14257-04 Bezel, Left Rear
54 1 14257-03 Bezel, Left Front
55 10 15001-29 Screw
56 5 14301 Knob
57 5 14302-01 Bezel Lens, Light Violet
58 1 12304 D Burner Base Assy.
59 1 12270 D Simmer Ring
60 1 91635 New Bracket, Light
61 1 12274 D Port Ring
62 2 12268-01 Grate, Left & Right
63 1 12269-01 Grate, Center
64 - 91595-01 Tube, Simmer, Left/Front
65 - 91595-02 Tube, Simmer, Left/Rear
66 - 91595-03 Tube, Simmer, Center
67 - 91595-04 Tube, Simmer, Right/Rear
68 - 91595-05 Tube, Simmer, Right/Front
69 - 91595-06 Tube, Main, Left/Front
70 - 91595-07 Tube, Main, Left/Rear
71 - 91595-08 Tube, Main, Center
72 - 91595-09 Tube, Main, Right/Rear
73 - 91595-10 Tube, Main, Right/Front
74 12 K-14355 Feet, Replacement Kit
75 1 12272 D Burner Cap
76 - 16416-01 Lower Harness
77 - 16416-03 Upper Harness
- - K-16416-02 Electrode Wire Kit
